Gear Combined Pump — Combined Pump for fuel dispensing and station equipment.
CP2 is a gear-type combination pump for fuel dispensers and station equipment. The range covers CP2, CP2A, CP2B and the higher-flow CP2C.
It runs at 990 rpm from a 0.75 kW motor, delivering 45–55 L/min (75–85 L/min for CP2C), with a dry vacuum of 0.054 MPa or better and a noise level of 72 dB or less.
| Parameter | Value |
|---|---|
| Model | CP2 |
| Collocate motor | 0.75Kw |
| Speed | 990rpm |
| Flow rated (CP2 / CP2A / CP2B) | 45–55L/min |
| Flow rated (CP2C) | 75–85L/min |
| Dry degree of vacuum | ≥0.054MPa |
| Noise level | ≤72dB |
| Output pressure | 0.18MPa – 0.24MPa |
CP2 is a gear-type combination pump for fuel dispensers and station equipment. The family covers CP2, CP2A and CP2B at 45–55 L/min, plus the higher-flow CP2C at 75–85 L/min, all from the same 0.75 kW motor running at 990 rpm.
Dry vacuum is 0.054 MPa or better, noise is at or below 72 dB and output pressure is 0.18–0.24 MPa. Because the four variants share a body, a site can change flow capacity by changing the variant rather than the mounting.
Tell us the dispenser brand the pump is going into and the flow the nozzle is rated for. CP2C is only worth specifying where the site actually pulls high flow; on standard lanes the CP2, CP2A or CP2B build is the better match.
