A centrifugal side-channel pump in a horizontal layout, supplied with 4, 6 or 8 impeller stages. The shaft runs on a mechanical seal that needs no cooling water. With a higher flow rate and a higher maximum working pressure than the DT-LPGP range, it suits bulk transfer and tanker unloading duties on longer lines.
| Parameter | DT-PSC-3004 | DT-PSC-3006 | DT-PSC-3008 |
|---|---|---|---|
| Stages | 4 | 6 | 8 |
| Flow rate | 7 m³/h | ||
| Max. working pressure | 1.4 MPa | 2.0 MPa | 2.8 MPa |
| Speed | 1 450 rpm | ||
| Motor power | 3 kW, 380 V 50 Hz | 4 kW, 380 V 50 Hz | 5.5 kW, 380 V 50 Hz |
| Direction of rotation | Anti-clockwise, facing the pump drive end | ||
| Connecting flanges | Inlet DN65 / outlet DN32 | ||
| Bearings | Sliding bearing at pump end, ball bearing at drive end | ||
| Lubrication | Pump-end bearing by pumped medium; drive-end bearing self-lubricating | ||
| Ambient temperature | −30 °C to +60 °C | ||
