Heavy-duty automatic shut-off nozzle, 1-1/2″ and 2″ — venturi type with dual poppets for high inlet pressure.
The heavy end of the automatic range: venturi-type automatic shut-off mechanism in a light aluminium body, with a two-position hold-open device and one-hand control of flow rate.
The right-angle design provides a larger lever area for better grip and easier control, permitting the nozzle to fit into awkward spaces close to walls and into corners. Dual poppets make the nozzle easy to open against high inlet pressure.
| Parameter | Value |
|---|---|
| Max Working Pressure | 0.35 MPa |
| Spout External Diameter | 35 mm |
| Inlet Size | 1-1/2″ / 2″ |
| Thread | NPT / BSP |
| Net Weight | 2.10 kg |
| Body | Aluminium |
| Main Stem | Stainless steel |
| Packing | Graphite with Teflon |
| Main Disc | Viton |
Final values are confirmed per order — contact our engineering team for the drawing, the certificate set and the spare-parts list.
Tell us your inlet size (1-1/2″ or 2″) and thread — we will confirm stock and quote within 24 hours.
Request a quotation
