DN25 automatic nozzle for gasoline, diesel and aviation fuel — 130 L/min with a stronger main valve spring.
The DT-ZVA25 steps up to a 31 mm spout and a 130 L/min maximum flow for bigger tanks — designed for gasoline, diesel and aviation fuel, with a stronger main valve spring for reliable shut-off at the higher flow.
Body and spout are aluminium with a brass fitting swivel, keeping the weight at 1.5 kg despite the larger bore.
| Parameter | Value |
|---|---|
| Spout External Diameter | 31 mm |
| Working Pressure | 0.05 – 0.35 MPa |
| Max Flow Rate | 130 L/min |
| Swivel | Female / Male, 1″, NPT / BSP |
| Nozzle Weight | 1.5 kg |
| Swivel Weight | 0.34 kg |
| Body / Spout | Aluminium |
| Fitting Swivel | Brass |
Final values are confirmed per order — contact our engineering team for the drawing, the certificate set and the spare-parts list.
Tell us your flow rate, swivel thread and media — we will confirm stock and quote within 24 hours.
